3600mm 100T/day economical paper mill machine one wire machine

Description

This paper mill machine is used to produce, flute corrugated paper, high strength fluting paper and fluting paper based on the GSM of 50-170g/m² . This 3600mm 100T/day fluting paper making machine is composed of wire forming section, press section, dryer section, paper reeling section, base section and auxiliary system etc.

Process flow of the 3600mm 100T/day fluting paper making machine

This paper mill machine is suitable to produce fluting paper and high strength fluting paper, which is 3200mm net paper width and paper weight 70-230g/ m². Whole production flow as below:

Open type headbox→ One wire →Two big jumbo roll press →Dryer cylinder group → sizing machine→Dryer cylinder group → Horizontal reeling machine

Structure of this 3600mm 100T/day fluting paper making machine

Main technical parameters

Technology Condition

• Raw material: OCC
• Transverse shrinkage(average):≤3.5-4.5%
• Transverse moisture difference: ≤±1.0%
• Transverse grammage deviation: ≤±1.5%
• Compressed air pressure: ≤0.6MPa

Warranty period of the 3600mm 100T/day fluting paper maching machine

All equipment of this 3600mm 100T/day fluting paper making machine’s warranty period: 12 months after normal production running. Bearing and rubber article’s warranty period: 12 months after normal production running. Supplier (our side) provide life-long maintenance of the equipment. Both supplier and customer need to negotiate the cost which will happen.

The warranty period start from the paper making machine’s normal production running. If something break down during warranty period, supplier will arrange professional workers to solved problems in scene. When shipment the equipment, supplier will provide the paper making machine’s general assembly drawing , foundation drawing, drive drawings and equipment instructions, schedule of engineering equipment, ect technical documents. If there is something change, will provide change file accordingly.

Working standard

Drawing size: Metric system

Material: GB (CNS)

Manufacture: GB (CNS)

Spray lacquer: GB (CNS)

Packing: GB (CNS)
